Gravograph CO2 Laser Cutting & Engraving Machines

Boxford have supplied Gravograph lasers for education use for over fifteen years...

Boxford are the sole distributor of Gravograph machines into education and training in the UK.

​



      All Gravograph lasers include:

​

  • Auto-focus

  • Integrated air cooling system for RF laser tube source

  • Windows software and drivers, including LaserStyle CAD software

  • 3 years parts and labour warranty (excluding consumable items)

Gravograph LS100 laser

Gravograph LS100

460mm x 305mm work area

Power             Up to 60w

Weight            upto 145kg

Dimensions    approx. 1180 x 880 x 760

​

Resolution          50 - 1200 DPI

Mounting             Bench or floor

Engraving speed     2000mm/sec

From:

POA

More info
Gravograph LS1000 XP laser

Gravograph LS1000XP

1220mm x 610mm work area

Power             up to 150w

Weight            up to 230kg

Dimensions    1660 x 1110 x 1360

​

Resolution          50 - 1200 DPI

Mounting               Floor only

Engraving speed     4000mm/sec

From:

POA

More info
Gravograph LS100 Ex laser

Gravograph LS100Ex

610mm x 305mm work area

Power             up to 60w

Weight            up to 190kg

Dimensions    approx. 1180 x 880 x 1025

​

Resolution          50 - 1200 DPI

Mounting               Bench of floor

Engraving speed     2500mm/sec

From:

POA

More info
Gravograph laser cutting software

Software (LaserStyle™)

Intuitive and easy to use software which links directly with your machine

Import a wide range of file formats including: AI, dxf, dwg, jpeg, bmp and more...

​

Print driver technology which can connect directly to a PC or network.

From:

Included

Watch video
Gravograph LS900 laser

Gravograph LS900

610mm x 610mm work area

Power             up to 80w

Weight            up to 215kg

Dimensions    approx. 1330 x 1300 x 950

​

Resolution          50 - 1200 DPI

Mounting               Floor only

Engraving speed     2000mm/sec

From:

POA

More info
Gravograph filtered extraction system

Optional Accessories

A selection of optional accessories for Gravograph machines include:

Automated rotary device for cylindrical objects

​

Integrated fume extraction/air filtration system

​

Additional focal lenses: 38.1mm, 63.5mm, 89mm and 100mm

From:

POA

More info

Which machine would you like a quote for?

Optional extras:

Thank you for your enquiry, once received, we'll send you a quotation within the next 24 hours

Please be aware our normal working hours are 8.30 - 17.00 (GMT) Mon-Fri

Finance options available upon request

We offer a range of finance options to help you make your next machine

investment. Speak to a member of our team who will be able to help...

+44 (0)1422 324810

We also supply our own range of affordable laser cutting and engraving machines...

Our welding simulator can take your students confidence and welding ability to the next level, before they enter the weld bay.
